EXCLUSIVELY SAFE
CASTLE 360EX WHITE is equipped with Deepcool’s exclusive Anti-leak Technology.
The technology helps the system achieve an automated pressure balance, which will significantly improve operation safety of AIO liquid cooling systems.
With this technology, Deepcool is setting a new standard for liquid cooling systems.
EXTRAORDINARY COOLING
STRONGER MOTOR
Driven by a 3-phase, x-life motor, and a pressure charging impeller, CASTLE 360EX WHITE’s pump is more powerful yet more quiet.
EXTRAORDINARY COOLING
MORE EFFICIENT FLOW
With more rounded corners and optimized flow route, the upgraded double chamber design increases the heat exchange efficiency, and decreases the operation noise and energy loss.
EXTRAORDINARY COOLING
MORE EFFICIENT FLOW
With 25% more skived fins on backside of the copper base, the heat absorption area is extensively increased.
EXTRAORDINARY COOLING
BEST MATCHING FANS
3 specially tuned TF120 S fans are included (in matching the radiator’s properties). The fans are also equipped with patented two-layer fan blades and flow-amplifying & noise-canceling frames.
EXCITING EXPERIENCE
CUSTOMIZABLE LOGO
The logo is upside down? Twist off the pump cap, adjust(4 directions in total), and twist back on. Easy!
Want to change the logo? An extra logo chip is included. Buy or make your favorite logo and stick on. Fun!
Mode+
Speed (Hold for 3 seconds to switch on/off)
Mode-
EXCITING EXPERIENCE
ADDRESSABLE RGB
Equipped with a mirror finish, immersive lighting and infinitive visual effects, CASTLE 360EX WHITE inherited its familial fabulous appearance. Its Addressable RGB lighting is adjustable through the 5V motherboard SYNC function or through an included controller.
Dynamic
Static
Breathing
Comet
Fashion Collision
Anti-leak Tech Inside, exclusively safe.
25% more skived fins on the back side of the copper base, the heat absorption area extensively increased.
Flow route optimized to reduce operation noise and energy loss.
3 specially tuned TF120 S fans are included (in matching the radiator's properties).
Customizable Logo, exciting DIY experience.
Ultra large copper base, extensive compatibility (including TR4).
5V Addressable RGB, adjustable through the motherboard, or included the controller.

Bewerbung

Intel

LGA20XX/1151/1150/1155/LGA1366
AMD

TR4/AM4/AM3+/AM3/AM2+/AM2/FM2+/FM2/FM1

Technischer Spezifikationen

Radiator Maße 402×120×27 mm
Radiator Material Aluminum
Nettogewicht 1705 g
Tube length 465 mm
Pump Größes 86×75×71 mm
Pumpe Geschwindigkeit 2550 RPM±10%
Pump Geräusch 17.8 dB(A)
Pumpe Anschluss 3-pin
Pumpe Nennspannung 12 VDC
Pump Nennstrom 0.2 A
Pumpe Stromverbrauch 2.4 W
Lüfter Maße 120×120×25 mm
Lüfter Geschwindigkeit 500~1800 RPM±10%
Fan Airflow 64.4 CFM
Lüfter Luftdruck 2.33 mmAq
Fan Geräusch ≤32.1 dB(A)
Lüfter Anschluss 4-pin PWM
Lagertyp Hydro Bearing
Lüfter Nennspannung 12 VDC
Lüfter Nennstrom 0.15 A
Lüfter Stromverbrauch 1.8 W
LED Typ Addressable RGB LED
LED Connector 3-pin(+5V-D-G)
LED Nennspannung 5 VDC
LED Power Consumption 2.25 W(PUMP)
EAN 6933412726869
P/N DP-GS-H12W-CSL360EXWH
